Forklift Drive Axles

Drive Axle for Forklift - A lift truck drive axle is a piece of machinery which is elastically affixed to a vehicle frame utilizing a lift mast. The lift mast is attached to the drive axle and is capable of being inclined around the drive axle's axial centerline. This is accomplished by no less than one tilting cylinder. Forward bearing elements combined with back bearing parts of a torque bearing system are responsible for fastening the drive axle to the vehicle framework. The drive axle can be pivoted around a swiveling axis oriented transversely and horizontally in the vicinity of the rear bearing elements. The lift mast is also capable of being inclined relative to the drive axle. The tilting cylinder is attached to the vehicle framework and the lift mast in an articulated fashion. This allows the tilting cylinder to be oriented almost parallel to a plane extending from the swiveling axis to the axial centerline.

Model H35, H40, and H45 forklifts, which are produced by Linde AG in Aschaffenburg, Germany, have a connected lift mast tilt on the vehicle framework itself. The drive axle is elastically affixed to the frame of the forklift by many different bearings. The drive axle consists of tubular axle body along with extension arms attached to it and extend rearwards. This kind of drive axle is elastically affixed to the vehicle framework utilizing back bearing parts on the extension arms together with forward bearing tools situated on the axle body. There are two rear and two front bearing tools. Each one is separated in the transverse direction of the vehicle from the other bearing device in its respective pair.

The drive and braking torques of the drive axle on this unit of forklift are sustained by the extension arms through the back bearing parts on the frame. The forces created by the load being carried and the lift mast are transmitted into the floor or roadway by the vehicle framework through the front bearing components of the drive axle. It is essential to be sure the components of the drive axle are put together in a firm enough way to maintain stability of the forklift truck. The bearing components can minimize minor bumps or road surface irregularities all through travel to a limited extent and give a bit smoother function.
